| 型号 |
螺纹尺寸（mm） |
壁厚度（mm） |
扳手尺寸 (MM) |
|
PG7 |
12.5 |
5 |
18 |
|
PG9 |
15.2 |
5 |
22 |
|
PG11 |
18.6 |
5 |
24 |
|
PG13.5 |
20.4 |
5 |
27 |
|
PG16 |
22.5 |
5.4 |
29 |
|
PG19 |
24 |
6 |
30 |
|
PG21 |
28.3 |
6.5 |
36 |
|
PG25 |
30 |
6.5 |
38 |
|
PG29 |
37 |
7 |
46 |
|
PG36 |
47 |
7 |
60 |
|
PG42 |
54 |
8 |
65 |
|
PG48 |
59.3 |
7 |
70 |
|
PG63 |
71 |
7 |
83 |
|
M12 |
12 |
5 |
18 |
|
M16 |
16 |
5 |
22 |
|
M18 |
18 |
5 |
24 |
|
M20 |
20 |
5 |
27 |
|
M22 |
22 |
5 |
30 |
|
M24 |
24 |
5 |
30 |
|
M25 |
25 |
6 |
33 |
|
M27 |
27 |
6 |
36 |
|
M30 |
30 |
7 |
38 |
|
M32 |
32 |
6 |
40 |
|
M36 |
36 |
7 |
46 |
|
M40 |
40 |
7 |
50 |
|
M50 |
50 |
7 |
60 |
|
M63 |
63 |
7 |
75 |
|
PG29 |
26 |
7 |
46 |
|
PG36 |
23 |
7 |
60 |
|
PG42 |
40 |
8 |
65 |
|
PG48 |
45 |
7 |
70 |
|
PG63 |
54.5 |
7 |
83 |
| 皮圈型号 |
内径（mm） |
外径（mm） |
高度（mm） |
|
PG7/M12 |
6.7 |
8.8 |
7 |
|
PG9/M16 |
8.5 |
11 |
7 |
|
PG11/M18 |
10.5 |
13.8 |
9 |
|
PG13.5/M20 |
9.2 |
16 |
9 |
|
PG16/M22 |
14.5 |
18 |
8.8 |
|
PG19/M24 |
12 |
19 |
9.5 |
|
PG21/M25/27 |
16 |
22 |
11 |
|
PG25/M30/32 |
21 |
25.5 |
11 |
|
PG29/M36 |
26 |
30 |
14 |
|
PG36/M40 |
23 |
40 |
15 |
|
PG42/M50 |
40 |
46 |
17 |
|
PG48/M63 |
45 |
51 |
17 |
|
PG63 |
54.5 |
60 |
17 |
| 皮垫型号 |
内径（mm） |
外径（mm） |
高度（mm） |
|
PG7/M12 |
12 |
18 |
1.5 |
|
PG9/M16 |
15.2 |
20 |
1.5 |
|
PG11/M18 |
18 |
24 |
1.8 |
|
PG13.5/M20 |
20 |
26 |
1.8 |
|
PG16/M22 |
22 |
28 |
1.8 |
|
PG19/M24 |
24 |
30 |
1.5 |
|
PG19/M25 |
25 |
30 |
1.5 |
|
PG21/M27 |
27 |
33 |
1.8 |
|
PG25/M30 |
30 |
34 |
1.8 |
|
PG25/M32 |
32 |
38 |
1.8 |
|
PG29/M36 |
36 |
42 |
1.8 |
|
PG36 |
46 |
56 |
1.3 |
|
M40 |
40 |
48 |
1.5 |
|
PG42 |
53 |
64 |
1.2 |
|
PG42/M50 |
50 |
60 |
1.2 |
|
PG48 |
59 |
70 |
2 |
|
PG48/M63 |
62 |
72 |
1.5 |
|
PG63 |
70 |
79 |
1.8 |
