产品优势
尼龙不锈钢嵌片扎带
采用尼龙66材质制成
绝缘性能好
难燃性 操作方便
产品参数
|
产品： |
尼龙不锈钢嵌片扎带 |
|
材质： |
ul-94v-2尼龙66，耐高温，耐酸耐腐蚀，绝缘性好，不易老化。 |
|
产品认证： |
CE SGS UL IS9001 |
|
用途： |
头部采用不锈钢片材，抗拉强度大于标准尼龙扎带 |
|
颜色： |
天然/黑色 |
|
操作温度： |
-25℃-60℃ |
|
型号 |
长 |
宽 |
捆扎范围 |
承受力 |
|||||
|
INCH |
MM |
MM |
MM |
LBS |
KGS |
||||
|
BS-3X100PLT |
4” |
100 |
3.0 |
3-22 |
22 |
10 |
|||
|
BS-4X100PLT |
6” |
150 |
4.0 |
3-35 |
44 |
20 |
|||
|
BS-4X200PLT |
8” |
200 |
5.0 |
3-50 |
44 |
20 |
|||
|
BS-5X250PLT |
10” |
250 |
5.0 |
3-65 |
55 |
25 |
|||
|
BS-5X300PLT |
12” |
300 |
8.0 |
3-82 |
55 |
25 |
|||
|
BS-8X145PLT |
5 3/4”” |
145 |
8.0 |
4-30 |
130 |
60 |
|||
|
BS-8X175PLT |
7” |
175 |
8.0 |
4-40 |
130 |
60 |
|||
|
BS-8X200PLT |
8” |
200 |
8.0 |
4-50 |
130 |
60 |
|||
|
BS-8X240PLT |
9 1/2” |
240 |
8.0 |
4-56 |
130 |
60 |
|||
|
BS-8X300PLT |
12” |
300 |
8.0 |
4-80 |
130 |
60 |
|||
|
BS-8X400PLT |
15 3/4” |
400 |
8.0 |
4-100 |
130 |
60 |
|||
|
BS-10X300PLT |
12” |
300 |
10.0 |
10-80 |
200 |
90 |
|||
|
BS-10X350PLT |
14” |
350 |
10.0 |
10-90 |
200 |
90 |
|||
|
BS-10X400PLT |
15 3/4” |
400 |
10.0 |
10-105 |
200 |
90 |
|||
|
BS-10X450PLT |
17 3/4” |
450 |
10.0 |
10-115 |
200 |
90 |
|||
|
BS-10500PLT |
17 11/16” |
500 |
10.0 |
10-150 |
200 |
90 |
|||
